Water Pump Pressure Switch

KRS-5 House Water System Pump Spare Part Mechanical Pressure Switch

KRS-5 mechanical type water pump pressure switch totally automatic control according to the pressure setting. Used for double spring to adjust cut in & cut out pressure. It is suitable for single phase 110V-240V and three phases 400V water pumps.

PREV | NEXT

+ Contact us

Cable float level switch

KRS-5

Pressuer Adjustable
Auto Start Auto Stop
Water Shortage Protection
Water-proof Design

KRS-Series DETAILS & OPTIONS

Automatic control no manual operation is required.

Common Specifications

Material: Metal, Plastic

Max. current: 16(8)A

Min. cut-in: 15PSI

Max. cut-out: 100PSI

Flange: Steel

Cover color: Black

Pressure switch differential: 20 to 30PSI

Protection rating: IP44

Max. working temperature: 55 deg C

Features

- Pressure Switch Application: water pumps

- Made of high quality materials for strong strength and long durability

- When the system pipeline pressure reaches the upper limit, the power supply is automatically cut off and the pump stops working.

- When the system pressure reaches the lower limit, the power supply is automatically switched on and the pump starts to work.

- Suitable for water pumps, such as self-priming water pump, injection water pump, garden water pump, etc.

Specifications And Dimensions

Model: KRS-5(female)

Box size (cm): 10.5×6.7×10.5

Carton size (cm): 54×34×23

QTY/CTN: 50PCS

N.W (kg): 19

G.W (kg): 21

Model: KRS-5(male)

Box size (cm): 10.5×6.7×12.5

Carton size (cm): 54×26.5×35

QTY/CTN: 50PCS

N.W (kg): 19.5

G.W (kg): 22

Customization Optional configuration
for KRS-5 model

Rated Voltage: 110V/230V, 400V

Base Color: White plated or color plated

Pressure Range: 20-40PSI, 30-50PSI, 40-60PSI

Connection Tread: G1/4" Male 36mm, G1/4" Male 43mm, G1/4" Female fixed, G1/4" Female Rotary, G3/8" Female fixed, G3/8" Female rotary

KRS-Series SUITABLE FOR
ALL KINDS OF PUMPS

Many pumps now come bundled with a pressure controller, and some may even be pre-installed, streamlining the process of getting your pump and pump controller up and running.
